An Overview of Photosystem: Definition, Location, Function, Types, Steps, FAQs

Edited By Irshad Anwar | Updated on Jul 02, 2025 06:57 PM IST

What Are Photosystems?

Photosystems are protein and pigment complexes found in the thylakoid chloroplast membrane. These systems are involved in vital light-dependent reactions in photosynthesis. They capture light energy and convert it into chemical energy. There are mostly two major types of photosystems: Photosystem I (PSI) and Photosystem II (PSII).

The fact that photosystems are among the main parts of the process of photosynthesis is, on one hand, because they interact to trap light energy and later fuel the electron transfer chain. The latter leads to the generation of ATP and NADPH, both needed crucially for the light-independent reaction—that is, the Calvin cycle, which, in turn, is responsible for the synthesis of organic molecules. Had it not been for the photosystems, solar energy would not have found a proper way of getting harvested.

Photosystems are embedded in the thylakoid membrane in chloroplasts. The thylakoids are flattened sacs, which in turn, form stacks called grana where light-dependent reactions take place. This placement allows photosystems in the thylakoid membranes to absorb light most efficiently and transmit energy therein appropriately.

Photosystem Structure

Photosystems consist of a pigment and several components making up the complex, together specialising in capturing and converting light energy.

Light-Harvesting Complexes: These are simply arrays of pigments and protein molecules able to capture light energy, collecting it into the reaction centre.

Reaction Center: Consists of a cluster of chlorophylls and proteins where the principal photochemical reactions are initiated, such as electron transfer.

Accessory Pigments: Pigments which assist in the capturing of a wider wavelength range of light and protect the photosystem from damage caused by an over-excitation of light.

Photosystems

There exist two types of photosystems concerning their roles and features in the photosynthetic process.

Photosystem I (PSI)

Function and Significance: It is primarily meant for the capturing of light to oxidise plastocyanin and reduce NADP+ through electron transport from plastocyanin to ferredoxin and then to NADP+.

Absorption Spectrum: PSI peaks in absorption at 700 nm, known as P700.

Key Components of PSI: The reaction centre associated with P700 chlorophyll and the light-harvesting complex I plus related proteins.

Photosystem II (PSII)

Function and Significance: PSII is the photosystem that is responsible for initiating light-dependent reactions. It captures photons and utilises this energy to extract electrons from water molecules, producing oxygen as a by-product of the process.

Absorption Spectrum: PSII has a maximum absorption of 680 nanometers. This particular chlorophyll is called P680.

Notable Components: PSII comprises the reaction centre with P680 chlorophyll, light-harvesting complex II, as well as the oxygen-evolving complex.

Mechanism Of Function Of Photosystem II

Photosystem II represents the first complex that can be found in the whole line of light-dependent reactions and is intended to play a significant role in the initial stages of photosynthesis.

PSII absorbs light energy that excites the electrons in P680 chlorophyll to an energy level higher than that of the ground state.
Water-splitting complex: this is the complex that breaks down water molecules into electrons, protons, and oxygen.
Initiation of Electron Transport Chain: The excited electrons from P680 are transferred to the primary electron acceptor and then moved through an electron transport chain for the formation of a proton gradient to carry out ATP synthesis.

NEET Highest Scoring Chapters & Topics

Know Most Scoring Concepts in NEET 2024 Based on Previous Year Analysis.

Know More

Mechanism Of Photosystem I

Photosystem I functions after PSII in the electron transport chain of photosynthesis.

Light Absorption and Energy Transfer: Energy from light is absorbed by PSI to transfer the electrons of the P700 chlorophyll to a higher state.
Electron Transport and NADP+ Reduction: Excited electrons move to ferredoxin and then are used in the reduction of NADP+ to produce NADPH.
Cyclic and Non-Cyclic Photophosphorylation: When the electron returns to PSI, it provides ATP. When the electron moves from PSII to PSI, it results in the production of both ATP and NADPH.

Role Of The Photosystems In Light-Dependent Reactions

These are roles in the light-dependent reaction that help in the process of changing light energy into chemical energy.

Summary of Light Reactions: Energy derived from light absorbed by photosystems drives the generation of ATP and NADPH.
Electron Transport in the Z-Scheme: This shows how electrons are carried away from H2O by the photosystems through PS II and PSI to NADP+, establishing the proton gradient that drives the synthesis of ATP.
Production of NADPH and ATP: The energy that is absorbed by Photosystems I and II lies behind the synthesis of NADPH and ATP, which are the energy carriers involved in the light-independent reactions of the Calvin cycle.

Recommended Video On 'Photosystem Overview'

Frequently Asked Questions (FAQs)

1. What is the most prominent difference between Photosystem I and Photosystem II?

The electron passage to NADP+ generates NADPH for Photosystem I, while Photosystem II contains the initiation steps for light-induced water molecule splitting and oxygen production.

2. What is the role of photosystems in photosynthesis?

Photosystems are responsible for harvesting light energy and converting it to chemical energy. This, in turn, leads to the generation of the ATP and NADPH that will eventually power the Calvin cycle.

3. Why are photosystems embedded in the thylakoid membrane?

Since the thylakoid membrane is a location in which the light-dependent reaction could be carried out perfectly. This would enable the absorption of light and energy transfer to take place very effectively.

4. Why is the Z-scheme important for photosynthesis?

The Z-scheme is the electron flow from PSII to PSI, and it helps in understanding the energy changes that drive the synthesis of ATP and NADPH.

5. How have the photosystems evolved differently across varying plant species?

Photosystems have evolved in such a way that they could develop better ways of light absorption and energy conversion efficiency. They thus differ in structure and pigment composition across varying plant species.

6. What is the significance of the P680 reaction center in Photosystem II?

P680 is the primary pigment in the reaction center of Photosystem II. It's named for its peak light absorption at 680 nm. When P680 absorbs light energy, it becomes excited and donates an electron, initiating the electron transport chain. This is crucial because it's the starting point for the light-dependent reactions and enables the splitting of water molecules.

7. How do herbicides targeting photosystem II work?

Many herbicides, such as atrazine and diuron, work by binding to the QB site on the D1 protein of Photosystem II. This prevents the transfer of electrons from QA to QB, disrupting the electron transport chain. As a result, the plant can't produce enough ATP and NADPH for the Calvin cycle, leading to its death. Understanding this mechanism is crucial for developing effective and safe herbicides.

8. What is the significance of the oxygen-evolving complex in Photosystem II?

The oxygen-evolving complex (OEC) is a crucial component of Photosystem II responsible for splitting water molecules. It contains a cluster of manganese and calcium ions that catalyze the oxidation of water to produce oxygen, protons, and electrons. This process is vital as it provides the electrons needed to replace those excited in the P680 reaction center and contributes to the proton gradient used in ATP synthesis.

9. Why is water splitting important in Photosystem II?

Water splitting, or photolysis, is crucial in PSII because it provides the electrons needed to replace those lost by P680 when it's excited by light. This process also releases protons (H+) into the thylakoid lumen, contributing to the proton gradient used for ATP synthesis. Additionally, it produces oxygen as a byproduct, which is essential for most life on Earth.

10. What is the role of plastoquinone in the electron transport chain?

Plastoquinone is a mobile electron carrier in the thylakoid membrane. It accepts electrons from Photosystem II and transfers them to the cytochrome b6f complex. This transfer is coupled with the movement of protons from the stroma to the thylakoid lumen, contributing to the proton gradient used for ATP synthesis. Plastoquinone's mobility is crucial for connecting the electron transport between PSII and the cytochrome b6f complex.

11. What is the significance of P700 in Photosystem I?

P700 is the primary pigment in the reaction center of Photosystem I, named for its peak absorption at 700 nm. When P700 absorbs light energy, it becomes excited and donates an electron to the electron transport chain. This high-energy electron is ultimately used to reduce NADP+ to NADPH, which is crucial for the Calvin cycle. P700's ability to be re-reduced by electrons from PSII allows for the continuous flow of electrons in the Z-scheme.

12. How does cyclic electron flow differ from non-cyclic electron flow?

In cyclic electron flow, electrons from Photosystem I are recycled back to the cytochrome b6f complex instead of reducing NADP+ to NADPH. This process generates ATP without producing NADPH. Non-cyclic electron flow, on the other hand, involves both photosystems and results in the production of both ATP and NADPH. Plants can switch between these modes to balance their energy needs.

13. How does state transition help plants optimize photosynthesis?

State transition is a short-term adaptation mechanism that allows plants to balance the excitation of PSI and PSII under changing light conditions. When PSII is overexcited, some LHCII (Light-Harvesting Complex II) proteins detach from PSII and associate with PSI, redirecting more light energy to PSI. This process helps maintain efficient electron flow and prevents damage from excess excitation energy.

14. How do cyanobacteria perform photosynthesis without chloroplasts?

Cyanobacteria, unlike plants, don't have chloroplasts. Instead, their photosynthetic machinery, including both photosystems, is located in specialized internal membranes called thylakoids within their cell. These thylakoids are similar in function to those found in chloroplasts. This arrangement allows cyanobacteria to perform oxygenic photosynthesis much like plants, demonstrating the evolutionary relationship between cyanobacteria and chloroplasts.

15. What is the relationship between light intensity and photosystem efficiency?

The relationship between light intensity and photosystem efficiency is not linear. At low light intensities, efficiency increases with light intensity as more photons are absorbed. However, as light intensity increases, efficiency plateaus and eventually decreases. This is because at high light intensities, the photosystems become saturated and can't process the energy fast enough, leading to increased heat dissipation and potential damage. Plants have various mechanisms to protect against this, such as non-photochemical quenching.

16. How does the structure of a photosystem contribute to its function?

A photosystem's structure is perfectly adapted to its function. It consists of a light-harvesting complex (antenna complex) surrounding a reaction center. The antenna complex contains various pigments that capture light energy and funnel it to the reaction center. This arrangement maximizes light absorption efficiency and ensures that the reaction center receives enough energy to drive electron transfer.

17. What is the significance of the antenna complex in photosystems?

The antenna complex is crucial for efficient light harvesting:

18. What is the importance of the special pair of chlorophyll molecules in reaction centers?

The special pair of chlorophyll molecules in reaction centers (P680 in PSII and P700 in PSI) is crucial because:

19. What is the role of carotenoids in photosystems beyond light harvesting?

Carotenoids in photosystems have multiple roles beyond light harvesting:

20. How does the light spectrum affect photosystem function?

Different wavelengths of light affect photosystem function differently due to the absorption spectra of chlorophylls and accessory pigments. Photosystem II absorbs light most efficiently around 680 nm (red light), while Photosystem I peaks around 700 nm. Blue and red light are most effective for photosynthesis, while green light is less so (which is why plants appear green). Understanding these spectral dependencies is crucial for optimizing artificial lighting in greenhouses and vertical farming.

21. What is the evolutionary significance of the two photosystems?

The existence of two photosystems is believed to be the result of endosymbiotic events in early evolution. It's thought that PSI evolved first in anoxygenic photosynthetic bacteria. PSII, with its unique ability to split water, likely evolved later. The combination of these two systems in cyanobacteria allowed for oxygenic photosynthesis, which dramatically changed Earth's atmosphere and paved the way for complex life. This dual system persists in all oxygenic photosynthetic organisms today, showcasing its evolutionary success.

22. How do photosystems contribute to the production of oxygen in photosynthesis?

Oxygen production in photosynthesis is directly linked to Photosystem II:

23. How do photosystems relate to the light-independent reactions (Calvin cycle)?

While photosystems are part of the light-dependent reactions, they are crucial for the light-independent reactions (Calvin cycle) because:

24. What is a photosystem and why is it important in photosynthesis?

A photosystem is a complex of proteins and pigments in the thylakoid membrane of chloroplasts that captures light energy and converts it into chemical energy. It's crucial for photosynthesis because it initiates the light-dependent reactions, allowing plants to convert sunlight into usable energy for growth and survival.

25. How do Photosystem I and Photosystem II differ in their functions?

Photosystem I (PSI) and Photosystem II (PSII) have distinct roles in the light-dependent reactions. PSII initiates the process by splitting water molecules, releasing oxygen and electrons. PSI uses the electrons from PSII to reduce NADP+ to NADPH. Together, they work in a series to drive the electron transport chain and produce ATP and NADPH for the Calvin cycle.

26. Why is Photosystem II named "II" when it comes first in the electron transport chain?

The naming of Photosystem II and I is based on the order of their discovery, not their sequence in the electron transport chain. PSII was discovered after PSI, hence the seemingly counterintuitive numbering. This often confuses students, but it's important to remember that PSII does indeed operate first in the electron flow during photosynthesis.

27. What role do accessory pigments play in photosystems?

Accessory pigments, such as carotenoids and chlorophyll b, expand the range of light wavelengths that can be absorbed for photosynthesis. They capture light energy and transfer it to chlorophyll a in the reaction center. This increases the overall efficiency of light harvesting and allows plants to utilize a broader spectrum of sunlight.

28. How does the Z-scheme relate to the two photosystems?

The Z-scheme is a visual representation of the electron flow through both photosystems during the light-dependent reactions. It shows how electrons are excited to higher energy levels in PSII, then lose energy as they flow through the electron transport chain, before being re-energized in PSI. The Z-shape of the diagram reflects the energy levels of the electrons at different stages of the process.

29. What is the quantum yield of photosynthesis and why is it important?

The quantum yield of photosynthesis refers to the number of molecules of a product (like oxygen or fixed carbon) produced per photon of light absorbed. It's an important measure of photosynthetic efficiency. In ideal conditions, the theoretical maximum quantum yield is about 0.125, meaning eight photons are required to fix one molecule of CO2. Understanding quantum yield helps in assessing plant productivity and in developing more efficient crop varieties.

30. What is the significance of the Q-cycle in photosynthetic electron transport?

The Q-cycle, occurring in the cytochrome b6f complex, is an important process that increases the efficiency of proton pumping during electron transport. It involves the oxidation and re-reduction of plastoquinone, effectively doubling the number of protons pumped into the thylakoid lumen for each electron passed through the complex. This amplification of the proton gradient enhances ATP production, making the overall process of photosynthesis more efficient.

31. How does the pH gradient across the thylakoid membrane relate to photosystem function?

The pH gradient across the thylakoid membrane is created by the accumulation of protons in the thylakoid lumen during the light-dependent reactions. This gradient is essential for ATP synthesis via chemiosmosis. The low pH in the lumen also activates protective mechanisms in PSII, such as non-photochemical quenching, which helps dissipate excess energy and prevent damage to the photosystem under high light conditions.

32. How do plants protect their photosystems from damage under high light conditions?

Plants have several mechanisms to protect their photosystems from damage under high light conditions:

33. What is the role of iron-sulfur clusters in Photosystem I?

Iron-sulfur clusters in Photosystem I play a crucial role in electron transfer. They act as electron acceptors, facilitating the movement of electrons from the excited P700 reaction center to ferredoxin. There are three iron-sulfur clusters in PSI: Fx, FA, and FB. These clusters form a electron transfer chain within PSI, allowing for efficient and directional electron flow. Their unique properties enable them to accept and donate electrons rapidly, which is essential for the high-speed electron transfer in photosynthesis.

34. How do photosystems contribute to the production of ATP and NADPH?

Photosystems contribute to ATP and NADPH production in several ways:

35. How do environmental factors like temperature affect photosystem function?

Temperature significantly affects photosystem function:

36. What is the role of plastocyanin in connecting the two photosystems?

Plastocyanin is a small, mobile copper-containing protein that plays a crucial role in connecting PSII and PSI:

37. How do photosystems contribute to the proton gradient across the thylakoid membrane?

Photosystems contribute to the proton gradient in several ways:
